What Is My Ford 2021 F-150 Towing Capacity?

How much towing capacity f150?

The all-new 2021 Ford-150 is here to promise next-level performance. Redesigned to incorporate powerful features to handle the toughest terrains and jobs, this truck is a worthy investment.

It boasts exceptional power, torque, and towing capacity. This legendary vehicle also offers best-in-class payload capacity. So, no matter what the job demands, F150 can effortlessly get it done.

So, what is the towing capacity of a Ford F150?

The 2021 Ford F150 has everything needed to cater to your towing needs day in day out. With maximum towing capacity extending up to 14000 pounds and a range of options available to mix and match cargo beds, cabin size, drive train, and tow packages, the performance-packed 2021 Ford 150 is an ideal truck in the market.

In this article, we’ll discuss the towing capacity of the Ford F150 in detail. In addition, we’ll cover aspects that impact its towing capacity, the drivetrain and towing, cab configuration, etc.

The 2021 Ford F-150 Towing Capacity

The towing capacity of the 2021 Ford F-150 refers to the maximum weight the truck can safely tow without impacting its parts.

Based on the engine size and axle ratio, the towing capacity of F-150 varies between 8,200 lbs. to 14,000 lbs.

Presently, the truck offers six engine choices – with differing capacity, efficiency, and power output.

From conventional V8 power to innovative turbo diesel, the 2021 Ford F-150 has an engine type to suit your preferences.

To ensure optimum power utilization of a truck, it is necessary to understand aspects that affect its towing capability. The maximum weight a vehicle can tow is dependent on a myriad of factors.

8 Factors That Impact Your F150’s Towing Capacity

  1. Engine Type: The maximum weight your F-150 pickup truck can pull will largely depend on your engine choice.
  2. Cab Configuration: The type of bed configuration impacts the overall towing capability of the truck.
  3. Axle Ratio: With an increase in gear ratio, the towing capacity of your vehicle also increases.
  4. Drivetrain: There are two types of drivetrain rear-wheel-drive (4×2) and four-wheel drive (4×4). The four-wheel drivetrain provides good traction but causes a slight reduction in towing capacity.
  5. Wheelbase: Extending wheelbase and minimizing overhang can result in raising tow capacity.
  6. Payload: The towing capacity of your vehicle falls with increasing weight on it.
  7. GCWR (Gross Combined Weight Rating): This is the manufacturer’s recommended maximum load weight which comprises the weight of the trailer and items it is carrying.
  8. Towing Package: Towing packages help augment your truck’s towing capabilities. They optimize various components to uplift their functioning.

Though the maximum assured towing capacity for a fully equipped 2021, Ford F-150 is 14,000 pounds, and it is subject to vary depending on configurations and features chosen for your particular vehicle trim.

2021 Ford F-150 Towing Capacity And Engines

When it comes to deciding your truck’s towing capacity, the majority of influence comes from the engine type selected.

As discussed above, the 2021 Ford F-150 features six different engine types. So, let’s explore the hauling capabilities of each of these engine types.

Chart Of Towing Capacity By Engine

Engine Horsepowe Torque Maximum Towing Capacity
3.3-liter V-6 290 hp 265 lb-ft 8,200 pounds
5.0-liter V-8 400 hp 410 lb-ft 13,000 pounds
3.0-liter Power stroke Turbo Diesel V-6 250 hp 440 lb-ft 12,100 pounds
2.7-Liter EcoBoost V-6 325 hp 400 lb-ft 10,100 pounds
3.5-Liter EcoBoost V-6 400 hp 500 lb-ft 14,000 pounds
3.5-Liter PowerBoost V-6 Full Hybrid 430 hp 570 lb-ft 12,700 pounds

As evident from above, in terms of performance, all six engines outperform. While for maximum performance, you have to opt for a trim level equipped with a 3.5L EcoBoost V6 engine.

2021 Ford F-150 Drivetrain And Towing

Besides the engine, the drivetrain also impacts the towing capability of your Ford truck. It is one of the prominent factors to aid in your vehicle engine’s performance.

The 2021 Ford F-150 comes in two drivetrain options – rear-wheel-drive (4×2) and 4-wheel drive (4×4). Both of these drivetrains have their distinct advantages.

The rear-wheel-drive (4×2) drivetrain is suitable for heavy-duty towing as it ensures towing capacity of up to 14,000 pounds.

The 4-wheel drive (4×4) drivetrain has a somewhat lesser towing capacity which amounts to 13900 pounds.

Yet, this difference of 100 pounds is significant for individuals requiring a towing solution for heavy hauls.

Considering its capability, the (4×4) drivetrain is commonly used by businesses requiring tow trucks to work on slippery tracks for extra traction.

2021 Ford F-150 Cab Configuration And Towing Capacity

Another element that influences your vehicle’s towing capacity is cabin size.

The overall configuration of your cabin directly impacts the weight limit your tow truck can handle. Consequently, this leads to changes in payload and towing capacity.

The 2021 Ford F-150 comes in three cabin sizes: Regular, SuperCrew, and SuperCab. The Regular cab size has seating space for three people.

The SuperCrew and SuperCab configurations boast spaciousness allowing 5-6 individuals to sit comfortably. The new Ford F-150 also provides cargo beds in three different sizes, including 5.5, 6.5, and 8 feet.

Now let’s explore towing capacities for each type of cab configuration.

Cab Size Rear Legroom Maximum Towing Capacity
Regular Cab N/A 13,300 pounds
SuperCab 33.5 inches 14,000 pounds
SuperCrew 43.6 inches 14,000 pounds

The SuperCrew and SuperCab configurations can attain maximum tow capacity, i.e., 14,000 pounds, when fully equipped. With 13,300 pounds, the Regular configuration also offers a good bet.

However, when it comes to passenger space, SuperCrew excels. It features two seat rows and 43.6 inches of legroom space for rear seats, while Regular Cab has a single row seat configuration.

The front legroom space for all three cabin sizes is the same, which stands at 43.9 inches.

The 2021 Ford F-150 Trim Levels And Tow Package Options

Towing packages are add-ons meant to boost your vehicle’s capabilities. The 2021 Ford F-150 lineup has seven trim levels – XL, XLT, Lariat, King Ranch, Platinum, Limited, and Tremor.

When chosen and installed correctly, the trim level and tow package can enhance the towing capacity of the entire setup.

The Ford trucks offer the following payload packages.

Let’s discuss each in detail.

1. Trailer Tow Package

The most basic towing package offered by the 2021 Ford F-150 is the Trailer Tow Package. This package is configured to provide everything needed for a full-size pick-up truck. The package includes:

  • 4-pin/7-pin wiring harness
  • Class IV trailer receiver hitch
  • Smart Trailer Tow Connector
  • 36-gallon fuel tank
  • Tailgate LED
  • Pro Trailer Backup Assist
  • Trailer brake controller

2. 2.7L V6 Ecoboost Payload Package

As evident from its name, the 2.7L V6 EcoBoost Payload Package harnesses the power from the 2.7L V6 EcoBoost engine.

The potential of this engine with 325 horsepower and 400 lb-ft torque guarantees outstanding performance, irrespective of the task level intensity.

The package majorly relies on delivering optimum payload efficiency.

When paired with Trailer Tow Package, the 2.7L V6 EcoBoost Package brings the features of standard trailer tow, in addition to a 3.73 electronic-locking rear axle and 9.75-inch gear set.

3. Heavy-Duty Payload Package

Built to deliver high-end performance, the heavy-duty payload package is meant to handle tough jobs. It has the superior payload and performance-boosting capabilities.

The heavy-duty payload package can work in conjunction with Max Trailer Tow Package. Alternatively, it can also employ a 3.5L EcoBoost V6 engine or a 5.0L V8 engine as the power source.

When combined with a 3.5L EcoBoost V6 engine, you get 400 horsepower and 500 lb-ft of torque whereas, with a 5.0L V8 engine, you get 400 horsepower and 410 lb-ft torque.

Inclusive of the below-mentioned features, this package is robust enough to handle heavy pull and tow at construction sites.

  • 36-gallon fuel tank
  • 3.73 electronic-lock rear axle
  • Advanced springs
  • 9.75-inch gearset
  • All-terrain tires
  • 18-inch silver aluminum heavy-duty wheels

4. Max Trailer Tow Package

Last and most powerful- the Max Trailer Tow Package is an all-inclusive package packed with the latest technology upgrades and adjustments.

The package, when properly loaded, can attain the threshold towing capacity of 14,000 pounds. The distinguishing features of the Max Trailer Tow package include:

  • 36-gallon capacity fuel tank
  • Pro Trailer Backup Assist
  • 3.55 electronic-lock rear axle
  • 4 or 7 pin wired harness
  • (Class IV) trailer hitch receiver
  • Integrated trailer brake control
  • Renewed rear bumper
  • Smart Trailer Tow Connector

In addition to offering maximum towing capacity, the Max Trailer Tow package also assists you in navigating through narrow parking lanes.

Courtesy to Pro Trailer Backup Assist system that empowers the driver with better control. Just rotate the knob, and your Ford F-150 truck will steer the trailer in the right spot.

Special Towing Features For The 2021 Ford F-150

The 2021 Ford F-150 has been crafted to deliver whopping power and transmission.

Besides high-duty engines and tow packages, the Ford F-150 truck comes equipped with exceptional features to optimize its payload and towing capacity.

These special features help you tackle hauling along off-beat paths and tough terrains. So, let’s discuss all the ingenious towing features of the 2021 Ford F-150 in detail.

1. Better Control As You Tow

The 2021 Ford F-150 is equipped with an advanced Trailer to Sway control system, which combines with Roll Stability Control to help your vehicle maintain stability and control while towing in areas prone to high winds.

This feature adds additional control to your vehicle and is available on all trim options.

2. Descend Slopes Safely

Integrating Hill Descent Control, the Ford F-150 truck allows you to move down slopes at a specific set speed.

The feature works on a traction control system and anti-lock system to control slippage of trucks while descending a steep grade.

It consistently keeps on altering brake pressure to avoid the risk of any kind of hazard.

3. Sync Adjustment

The Trailer Brake Control system comes affixed in your F-150 truck’s instrument panel.

The feature ensures that your truck and electric trailer’s brakes are synched seamlessly for better performance and convenience.

The Trailer Brake Control utilizes vehicle speed, braking input, ABS logic to gain better control over the performance management of the vehicle.

4. All Round View

The high-definition cameras carefully installed around your Ford F-150 truck provide you a comprehensive view of the area surrounding your vehicle and trailer.

These cameras positioned on the grille, beneath the side view mirror, on the tailgate, and in bed ensure you keep a close watch on your cargo.

5. Pick Your Mode

The 2021 Ford F-150 lineup is available in selectable drive modes to let you adjust your truck’s performance according to your requirement and mood.

For regular drives, the 4×2 system is available in Normal mode. In addition, there is:

  • ECO Mode
  • Sport Mode
  • Tow/Haul Mode
  • Slippery Mode
  • Trail Mode to suit your driving preferences

The standard tow/haul mode is especially useful for efficient towing of heavy trailers. Moreover, for 4×4 configurations, Ford F-150 offers Deep Snow/Sand and Mud/Rut drive modes.

How To Unlock The 2021 Ford F-150’s Maximum Towing Capacity

To reach the maximum towing capacity of 14,000 pounds, you have to choose either SuperCab or SuperCrew cab configuration.

With SuperCrew, you’ll need:

  • Twin-turbocharged 3.5-liter EcoBoost V-6 engine (400hp)
  • 4×2 rear-wheel drive
  • Max Trailer Tow Package

With SuperCab, you’ll need:

  • EcoBoost V-6 engine (400hp)
  • Two-wheel drive
  • The Max Trailer Tow Package

As lower trims offer higher towing capacity, you have to choose between XL and XLT.

Conclusion

Undoubtedly, the 2021 Ford F-150 is one of the best full-size trucks available in the segment. It is capable of managing heavyweight and is ideal for travel trailers and campers.

The 2021 Ford F-150 is redesigned, keeping in view superior performance for heavyweight pulling. It is sturdy, robust, and detail-oriented to offer excellent towing capabilities in all terrains.

To enable it to pull weight as per your requirement, you have to use it with a particular engine type. However, attempting to tow weight more than as prescribed can raise safety issues.

So, always make sure to select the Ford F-150 engine that aligns with your towing requirement – because, as discussed above, different engines come with different towing capacities.
